50VA Rated Power Toroidal Transformer for Lighting

50VA Rated Power Toroidal Transformer for Lighting

    • 50VA Rated Power Toroidal Transformer for Lighting
    • 50VA Rated Power Toroidal Transformer for Lighting
    • 50VA Rated Power Toroidal Transformer for Lighting
    • 50VA Rated Power Toroidal Transformer for Lighting
    • 50VA Rated Power Toroidal Transformer for Lighting
    • 50VA Rated Power Toroidal Transformer for Lighting
    • 50VA Rated Power Toroidal Transformer for Lighting

    Dettagli:

    Place of Origin: CHINA
    Marca: IKP
    Certificazione: CE/UL/REACH/ROHS
    Model Number: Toroidal Transformer

    Termini di pagamento e spedizione:

    Minimum Order Quantity: 1000
    Prezzo: 3.00-20.00
    Packaging Details: Carton
    Delivery Time: 10-15 days
    Payment Terms: L/C, T/T
    Supply Ability: 100,000/week
    Contattaci
    Descrizione di prodotto dettagliata

    Specifications:

    • Power range:30VA to 1000VA

    • Input / Output: Customized

    • Insulation Class: UL class B, F, H, N (optional)

    • Isolation: 4KV (Hi-pot)

    • Easy to change diameter and height of the core

    • Customized specifications are welcome



    Rated Power

     (VA)

    Outside Dimension

    D*H(mm)

    Weight

    (kg)

    Temp. Rise

    (℃)

    		 Approval
    30 80*32 0.54 30 UL/CE/RoHS/CQC
    50 90*33 0.78 45 UL/CE/RoHS/CQC
    60 100*33 0.94 47 UL/CE/RoHS/CQC
    80 105*34 1.11 50 UL/CE/RoHS/CQC
    100 110*35 1.29 51 UL/CE/RoHS/CQC
    120 115*35 1.48 52 UL/CE/RoHS/CQC
    250 135*42 2.57 53 UL/CE/RoHS/CQC
    300 152*44 3.28 54 UL/CE/RoHS/CQC
    400 153*50 3.87 54 UL/CE/RoHS/CQC
    500 160*55 4.65 55 UL/CE/RoHS/CQC
    600 175*57 5.63 56 UL/CE/RoHS/CQC
    800 191*62 7.05 57 UL/CE/RoHS/CQC
    1000 192*70 8.00 58 UL/CE/RoHS/CQC


    50VA Rated Power Toroidal Transformer for Lighting◆We can design and manufacture customized part with specific requirement◆We can design and manufacture customized part with specific requirement



    50VA Rated Power Toroidal Transformer for Lighting50VA Rated Power Toroidal Transformer for Lighting50VA Rated Power Toroidal Transformer for Lighting50VA Rated Power Toroidal Transformer for Lighting
